ชุดต่อสายไฟแบบตัว T EVO02D

Gel-insulated T-junction for IP68 splices for low voltage 0.6/1 kV cables up to three poles. Directly laid underground, overhead, in conduits.
Even faster and easier installation due to new (improved) fracturable bulkheads and prefilled: no resin or gel to be poured

Max poles: Three

Through-wire cross-section (min-max): 1.5 – 4 ^mm2
Through-wire diameter (min-max): 10 – 13 mm

Branch cable cross-section (min-max): 1 – 2.5 ^mm2
Branch cable diameter (min-max): 6 – 8 mm

Kit contents: Pre-filled gel joint, Screw terminal block for copper-copper, aluminum-aluminum and copper-aluminum connections, Instructions
